Short Description:

Wire wound power inductor feature & characteristic:

★flat bottom surface ensures secure,reliable mounting

★the serees are characterized by low profile,low DC resistance,and high current handling capacities

★these parts can be used in high-density mounting configurations

★provided in enbossed carrier tape packaging for usr with automatic mounting machines


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Product Detail

    Product Tags

    Wire wound power inductor feature & characteristic:

    ★flat bottom surface ensures secure,reliable mounting

    ★the serees are characterized by low profile,low DC resistance,and high current handling capacities

    ★these parts can be used in high-density mounting configurations

    ★provided in enbossed carrier tape packaging for usr with automatic mounting machines

    Application:

    ★mobile phones,personal computers,hard disk drives,and others

    SMD POWER INDUCTORS

      SGA43 Series

    Type Inductance
    (uH)
    DCR
    (Ω Max)
    DCI
    (mA Max )
    S.R.F
    Min
    SGA43-1R0M 1.0 0.045 3.50 7.96MHz
    SGA43-1R4M 1.4 0.055 2.85
    SGA43-1R8M 1.8 0.06 2.80
    SGA43-2R2M 2.2 0.07 2.40
    SGA43-2R7M 2.7 0.075 2.30
    SGA43-3R3M 3.3 0.085 2.25
    SGA43-3R9M 3.9 0.09 1.70
    SGA43-4R7M 4.7 0.105 1.65
    SGA43-5R6M 5.6 0.12 1.60
    SGA43-6R8M 6.8 0.12 1.40
    SGA43-8R2M 8.2 0.14 1.30
    SGA43-100M 10 0.18 1.10 2.52MHz
    SGA43-120M 12 0.21 1.00
    SGA43-150M 15 0.235 0.85
    SGA43-180M 18 0.33 0.80
    SGA43-220M 22 0.36 0.70
    SGA43-270M 27 0.52 0.65
    SGA43-330M 33 0.54 0.60
    SGA43-390M 39 0.58 0.55
    SGA43-470M 47 0.84 0.48
    SGA43-560M 56 0.93 0.46
    SGA43-680M 68 1.11 0.44

    shape and dimensions

    Remark:

    ★Special inquiries besides the above common used types can be met on your requirement.

    SMD power choke

    wire wound power inductor

    power SMD inductor

    low profile power inductor
