Short Description:

SMD power inductor feature & characteristic:

★flat bottom surface ensures secure,reliable mounting

★the serees are characterized by low profile,low DC resistance,and high current handling capacities

★these parts can be used in high-density mounting configurations

★provided in enbossed carrier tape packaging for usr with automatic mounting machines


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Product Detail

    Product Tags

    SMD power inductor feature & characteristic:

    ★flat bottom surface ensures secure,reliable mounting

    ★the serees are characterized by low profile,low DC resistance,and high current handling capacities

    ★these parts can be used in high-density mounting configurations

    ★provided in enbossed carrier tape packaging for usr with automatic mounting machines

    Application:

    ★mobile phones,personal computers,hard disk drives,and others

    SMD inductor package types

    SMD POWER INDUCTORSSGA54 Series
    Type Inductance
    (uH)
    DCR
    (Ω Max)
    DCI(mA Max )  S.R.FMin
    SGA54-100M 10 0.10 1.65 2.52MHz
    SGA54-120M 12 0.12 1.55
    SGA54-150M 15 0.14 1.40
    SGA54-180M 18 0.15 1.25
    SGA54-220M 22 0.18 1.10
    SGA54-270M 27 0.20 0.95
    SGA54-330L 33 0.22 0.90
    SGA54-390L 39 0.30 0.80
    SGA54-470L 47 0.35 0.75
    SGA54-560K 56 0.40 0.70
    SGA54-680K 68 0.45 0.65
    SGA54-820K 82 0.60 0.60
    SGA54-101K 100 0.70 0.55 1 KHz
    SGA54-121K 120 0.85 0.45
    SGA54-151K 150 1.10 0.43
    SGA54-181K 180 1.35 0.40
    SGA54-221K 220 1.55 0.35

    shape and dimensions

    Remark:

    ★Special inquiries besides the above common used types can be met on your requirement.
